Archipelago Monitor Statistics

Archipelago (Ark): CAIDA's active measurement infrastructure serving the network research community since 2007.
Statistical information for the topology traces taken by this individual Ark monitor is displayed below. See the main statistics page for the full list of monitors


previous
Prev monitor: bwy-uk
Prev in UK: bwy-uk
Prev in Europe: bwy-uk
next
Next monitor: cdg-fr
Next in UK: lcy-uk
Next in Europe: cdg-fr

cbg-uk

University of Cambridge
Cambridge, UK (8)
IPv4 data used (switch to IPv6)
Time range2023-12-04 22:55 to 2023-12-05 08:13 UTC (9 hours) (105 days ago)
Total traces87000
Traces with responding destinations9879 (11.355%)
ASes with responding destinations1495 (17.874% out of 8364)
Prefixes with responding destinations5915 (15.447% out of 38291)
Protocol versionv4 (switch to v6)
Generated for cycle 11107 on 2023-12-06 13:39 UTC

All images can be clicked on for more detailed information.

Median RTT per country and US state

Mapping RTT by political boundaries can reveal where high latency issues are located.

Path Dispersion

The paths taken by different traces show where the majority of a monitor's traffic travels.

Path Length Distributions

Path length distributions show, on aggregate, how well-connected a monitor is to the rest of the Internet.
