Archipelago Monitor Statistics
Archipelago (Ark): CAIDA's active measurement infrastructure serving the network research community since 2007.
Statistical information for the topology traces taken by this individual Ark monitor is displayed below. See the main statistics page for the full list of monitors
To main statistics page
| Time range | 2026-02-07 14:28 to 17:40 UTC (3 hours) |
| Total traces | 54000 |
| Traces with responding destinations | 1 (0.002%) |
| ASes with responding destinations | 1 (0.016% out of 6444) |
| Prefixes with responding destinations | 1 (0.004% out of 27875) |
| Protocol version | v4 |
Generated for cycle 14265 on 2026-02-08 12:05 UTC
All images can be clicked on for more detailed information.
Median RTT per country and US state
Mapping RTT by political boundaries can reveal where high latency issues are located.
Path Dispersion
The paths taken by different traces show where the majority of a monitor's traffic travels.
-
AS Path Dispersion (by AS Hop)
AS connectivity near monitor
-
AS Path Dispersion (by IP Hop)
AS connectivity near monitor (with IP hop distances preserved)
-
IP Path Dispersion (by IP Hop)
IP connectivity near monitor
RTTs vs. Distance
Comparing RTT with geographical distance helps show if latency is primarily due to distance or other factors.
-
RTT density versus geographical distance
-
RTT quartiles versus geographical distance
