Statistical information for the topology traces taken by this individual Ark monitor is displayed below. See the main statistics page for the full list of monitors

Prev monitor: med-co
Prev in DE: lej-de
Prev in Europe: lpi2-se
Next monitor: mnz-us
Next in DE: muc-de
Next in Europe: mst-nl


Residential (Versatel)
Heidelberg, DE (9)
IPv4 data used (switch to IPv6)
Time range2020-10-17 03:48 to 13:15 UTC (9 hours) (770 days ago)
Total traces105000
Traces with responding destinations13551 (12.906%)
ASes with responding destinations1916 (20.327% out of 9426)
Prefixes with responding destinations7499 (17.188% out of 43629)
Protocol versionv4 (switch to v6)
Generated for cycle 8858 on 2021-05-05 09:56 UTC

All images can be clicked on for more detailed information.

Median RTT per country and US state

Mapping RTT by political boundaries can reveal where high latency issues are located.

Path Dispersion

The paths taken by different traces show where the majority of a monitor's traffic travels.

Path Length Distributions

Path length distributions show, on aggregate, how well-connected a monitor is to the rest of the Internet.
